How an Air Conditioner Works

As a homeowner, it’s always a good idea to learn as much as you can about your appliances. That means knowing their basic operations, what features are included, and if any necessary upkeep is involved. Needless to say, this is no exception for your air conditioning (AC) unit.

How It All Began

The modern air conditioner transfers cool air throughout your home to keep you comfortable during the year’s hottest months. Willis Haviland Carrier originally invented this marvel in 1902. He developed the air conditioner to solve a humidity problem at a printing plant in Brooklyn, New York. This invention was ultimately credited with creating a system of chilled coils to maintain a constant temperature.

Today, the Energy Information Administration (EIA) reports that 87 percent of homes in the United States use air conditioners. This usage accounts for nearly 12 percent of total energy costs each year. That’s why we at JMAC Plumbing and Air Conditioning want you to know about how your cooling system works. Additionally, this will help to keep your trusted investment running efficiently for years to come.

How It Works

As a consumer, it’s important to understand the key elements of your cooling system, and that starts with knowing your air conditioner’s five main functional components and how they work together:

1.  Compressor—the key to refrigerant conversion

The compressor is often considered the “heart” or “engine” of your air conditioner, as it acts like a pump inside your system. It is located in the outdoor portion of your system, which is referred to as the condenser. Once your thermostat activates the system, the compressor starts pulling in a low-temperature, low-pressure refrigerant in gas form from your system. The gas is then compressed to a higher pressure and temperature before being released to the condenser coil.

2.  Condenser—outdoor coil

The condenser coil is also located in the outdoor portion or your system. It’s made up of a piping sequence with thousands of small fins on it. The refrigerant runs through this coil after exiting the compressor. A fan pulls outside air across the coil to remove the heat from the refrigerant with the assistance of the fins for maximum heat disbursement. This process causes the refrigerant to convert back to a high-pressure liquid state prior to entering the expansion valve.

3.  Expansion valve—mechanical component regulating refrigerant

This critical part of the system is responsible for controlling the conversion and amount of refrigerant passed through to the evaporator. This is typically located on the indoor portion of your system. As it passes through, the valve forces the high-pressure liquid refrigerant through a small orifice, causing the pressure reduction.  At this point, rhe refrigerant expands to a liquid/vapor mix and enters the evaporator coil.

4.  Evaporator—indoor coil

The evaporator is a series of piping creating another coil that the liquid/vapor refrigerant passes through and absorbs the heat from the air passing over it. By way of its ductwork, it lowers the temperature of the air and distributes it throughout your home, thereby lowering the temperature throughout the space.” The cycle continues when the refrigerant makes its way back to the compressor to keep the air in your home regulated to the desired temperature setting on your thermostat.

5.  Blower—indoor fan

The blower is a fan that pulls warm air through the air filter in the return ductwork. It pushes that air over the evaporator coil and distributes it via your ductwork throughout your home.

In addition to cooling your home, an air conditioner can also help address humidity in your home by humidifying and dehumidifying. Some units include a moisture collection pan that absorbs the moisture from the air as the refrigerant absorbs heat.
